Example screenshot of Suzuki's official SDT scan tool while it is connected to ECU of a 2nd gen. DDiS Jimny. The same tool is used to access any other contemporary Suzuki vehicle.
The screen shows the readout of current fault codes on that vehicle. Multiple fault codes regarding the injection system are displayed.
Note the contents of the header on device's screen.
